Description

SAD-3588201 4324102227 AIR DRYER

1 Release thrust bearing, clutch 5136682/1.26.215 1 14 Support plate SZ804.21.305-1 1
2 Release sleeve, main clutch 5147787/1.26.214 1 15 Pin SZ904.21.304 1
3 Nut M8-Zn.D GB/T6170-2000 3 16 Sector plate unit SZ904.21.055 1
4 Washer 8-Zn.D GB/T7244-1987 3 17 Split pin 3.2×16-Zn.D GB/T97.1-2002 1
5 Sliding support, release sleeve SZ804.21.701 1 18 Bolt M10×1.25×25 GB/T5786-2000 2
6 Stud AM8-M8×28-8.8 GB/T899-1988 3 19 Rod unit (LWR) SZ700.21.031 1
7 Plain washer 8-Zn.D GB/T97.1-2002 1 20 Nut M12-Zn.D GB/T6170-2000 1
8 Split pin 2×12 GB/T91-2000 1 21 Adjusting nut, release cable 5104884SZ/1.26.206E 1
9 Rod unit (UPR) SZ804.21.050 1 22
Clevis, release cable
adjustment
SZ804.21.507 1
9.1 Rod (UPR) SZ804.21.501 1 23 Spring 5102356/1.26.522 1
9.2 Clevis SZ804.21.306 3 24 Pin, coupling yoke 8808026003/1.26 1
9.3 Shaft, Pin B6×24 GB/T 882-86 3 25 Release fork unit LY1054.21.014 1
9.4 Washer 6-Zn.D GB/T97.1-85 3 26 Release fork, main clutch 4993814/1.26.213 1
9.5 Split pin 2×16 GB/T91-2000 3 27 Screw, release fork, clutch 4968813/1.26.225 1
10 Spring, release fork 44011615/1.26.224 2 28 Adjusting screw SZ804.21.307 1
11 Nut M10-Zn.D GB/T6170-2000 1 29 Retainer ring 22 11067075/12245 1
12 Washer 10-Zn.D GB/T93-1987 3 30 Washer 22.5×38×2.5 4997848/1.26.033 1
13 Washer 10-Zn.D GB/T97.1-2002 2 31 Bolt M8×18-Zn.D GB/T5783-2000 4

32
Support unit, pedal, main
clutch
5120392/1.26.020
1

33 Drive link, pedal 5120396/1.26.037 1
34 Pedal unit SZ804.21.040 1
35 Bushing, seat, pedal 5110544/1.26.035A 2
36 Oil cup M8×1 GB/T1152-1995 2

1
Control lever assembly, auxiliary
clutch
5128770/1.26.506 1 8 Spring, release fork 44011615/1.26.224 2
1.01 Button assembly, handle, auxiliary clutch 5131448/1.26.521 1 9 Bearing 6014.2RS(GB278Bearing 80114) GB/T276 1
1.02 Handle 885128431/1.67.220 1 10 Release pusher, auxiliary clutch 4993817/1.26.530
1.03 Control lever unit, auxiliary clutch 8A5128449/1.26.502 1 11 Fork shaft unit, auxiliary clutch SZ804.21.060A 1
1.04 Spring, button, handle 5105729/1.67.253 1 12 Release fork, main clutch 4993814/1.26.213 1
1.05 Control lever, limit detent 5128713SZ/1.26.508 1 13 Return spring, cable, auxiliary clutch 5102356/1.26.522 1
1.06 Retainer ring 6 GB/T894.1-1986 1 14 Screw, release fork, clutch 4968813/1.26.225 1
1.07 Limit detent, parking 5110155/1.67.223 1 15
Adjusting plate, return spring, auxiliary
clutch
5145535/1.26.581 1
1.08 Pin, limit detent 5131437/1.67.260 1 16 Washer 16-Zn.D GB/T93-1987 1
1.09 Rivet, limit detent 4985127/1.67.227 1 17 Bolt M16×1.5×35 GB/T5786-2000 2
1.1 Sector plate, lever, auxiliary clutch SZ804.21.161 1 18 Split pin 2×12-Zn.D GB/T91-2000 2
1.11 Shaft, pin, control lever, parking brake 4988275/1.67.208 1 19 Plain washer 6-Zn.D GB/T97.1-2002 1
1.12 Retainer ring 14 GB/T894.1-1986 2 20 Release cable unit, auxiliary clutch 5126568/1.26.507B 1
1.13
Support, control lever, auxiliary
clutch
8A5128809/1.26.542 1 21 Adjusting nut, release cable 5104884/1.26.206E 1
2 Pin, cable, auxiliary clutch 4998004/1.26.504 1 22 Clevis, release cable adjustment SZ804.21.507 1
3 Cable ring nut 5126325/1.26.518 1 23 Shaft, Pin B6×20-Zn.D GB/T882-1986 1
4 Bracket unit (RR), cable 5126322/1.26.512A 1 1
5 Washer 8-Zn.D GB/T7244-1987 4
6 Nut M8-Zn.D GB/T6170-2000 4
7 Seat, release bearing, auxiliary clutch 4993816/1.26.514 1
