Description
SDLG WHEEL LOADER LG956V L956F AIR CONDITION
Air Filter Assembly F3/4L 912A-0000 1
15 Primary filter assembly SZ4105T.21.011 1
2 Transition support weldment, filter 4RCT4.220100-SZ 1
16 Clamp SZ4105T.21.204 1
3 Bolt M10×20-Zn.D GB/T5783-2000 4
4 Washer 10-Zn.D GB/T93-1987 4
5 Washer10-Zn.D GB/T97.1-2002 4
6 Bolt M8×30-Zn.D GB/70.1-2000 4
7 Washer 8-Zn.D GB/T7244-1987 6
8 Nut M8-Zn.D GB/T6170-2000 4
9 Bolt M8×20-Zn.D GB/T5783-2000 2
10 Bracket unit, air cleaner 4RTF.210350 1
11 Hose clamp（64-76） QC/T619-1999 2
12 Intake connecting hose 4RCT4.220006 1
13 Clamp（76-92） QC/T619-1999 2
14 Connection tube, air inlet SZ804.18.111 1
1 Muffler assembly SZ4108T.240100 1
2 Nut M10-Zn.D GB/T6170-2000 4
3 Washer 10-Zn.D GB/T93-1987 4
4 Studs AM10×25-Zn.D GB/T899-2000 4
5 Guard net 1 SZ4108T.24.102-1 1
6 Guard net 2 SZ4108T.24.103-1 1
7 Bolt M6×12-Zn.D GB/T5783-2000 4
8 Washer 6-Zn.D GB/T93-1987 4
9 Washer 6-Zn.D GB/T97.1-2000 4
1 Oil cooler assembly SZ4108T.460100LV 1
2 Nut M8-Zn.D GB/T6170-2000 4
3 Washer 8-Zn.D GB/T7244-1987 4
4 Bolt M8×25-Zn.D GB/T5783-2000 4
5 Oil outlet hose, radiator SZ4108T.460502A 1
6 Oil outlet pipe subassembly,
radiator
SZ4105T.460200 1
7 Oil inlet pipe subassembly,
radiator
SZ4105T.460300 1
8 Clamp19-29(Stainless steel) QC/T619-1999 4
9 Bolt M5×20-Zn.D GB/T5783-2000 1
10 Nut M5-Zn.D GB/T39-1988 1
11 Composite clip (UPR) 4RTF.460401-2 1
12 Composite clip (LWR) 4RTF.460402-2 1
13 Oil inlet hose, radiator SZ4108T.460501A 1
1 Gasket(Sponge) SZ700.47.164 1 13 Washer 8-Zn.D GB/T97.1-2002 2
2 Washer 8 GB/T93-1987 2 14 Sealing stripsⅡ SZ700.47.166 2
3 Seal plate unit (UPR) SZ804.19.016 1 15 Wind deflector Ⅱ SZ804.47.163 2
4 Radiator assembly SZ4108T.540000LV 1 16 Water outlet hose, radiator 4RTF.540006SZ 1
5 Nut M8-Zn.D GB/T6170-2000 4 17 Bolt M6×16-Zn.D GB/T5783-2000 4
6 Bolt M8×20-Zn.D GB/T5783-2000 2 18 Washer 6 GB/T93-1987 4
7 Clamp d54(Stainless steel) JB/T 8870-99 4 19 Nut M6-Zn.D GB/T 6177-2000 4
8 Water inlet hose, radiator 4RTF.540007AZ 1 20 Bolt M10X50-Zn.D GB/T5783-2000 2
9 Pin 3×16 -Zn.D GB/T91-2000 1 21 Washer 10-Zn.D GB/T93-1987 4
10 Pull rod 4RTF.540009AZ 1 22 Washer 10-Zn.D GB/T5287-2000 2
12 Washer 8-Zn.D GB/T7244-1987 6 23 Shock absorber SZ4108T.540020 2
24 Cushion plate SZ4108T.540021 2
25 Fan cowl SZ4108T.540000LV-000 1
26 Rap, radiator SXG-I-0.7 1
27 Overflow tank SZ804.19.030 1
28 Bolt 8×20-Zn.D GB/T5783-2000 1
29 Water overflow pipe SZ904.19.125 2
30 Grass windshield 4RTF540000-00-06 1
31 Drain cock assembly T/HS-203-0 1
