OA19084 FILTER HBXG SHEHWA 0A19084

1
Intermediate rod, foot throttle
control
8A1201001/1.10.024 1 12 Throttle pedal unit SZ804.20.050 1
2 Rod (FR), throttle control 1.10.0/8B08001001SZ-1 1 13 Pin 3×16 GB/T91-76 2
3 Washer 6-Zn.D GB/T97.1-2002 10 14 Washer 14 GB/T97-76 2
4 Split pin 2×12 GB/T91-2000 10 15 Damping block 5118180/1.83.070 1
5 Rocker assembly, throttle 885147282/1.10.031 1 16 Elastic cylindrical pin 4×24 BZ/JHX-SZ 1
6 Elastic cylindrical pin 3×16 BZ/JHX-SZ 1 17 Nut M5-Zn.D GB/T6170-2000 1
7 Live shaft unit, throttle 8A5116788/1.10.030 1 18 Bolt M5×40-Zn.D GB/T5782-2000 1
8 Washer 10 GB/T848-85 3 19
Leverage board unit, pedal,
throttle
5127675/1.10.020A 1
9 Retainer ring 9 GB/T896-86 1 20
Shaft unit, linkage, foot
throttle control
SZ804.20.080 1
10 Rod (RR), foot throttle control SZ804.20.184 1
11 Torsion spring 5127677/1.10.021 1

21 Shaft, Pin SZ804.20.301 1 37 Control lever linkage, hand throttle 5129632/1.10.053 1
22 Washer SZ804.20.302 1 38 Pressure plate SZ804.20.106 1
23 Pin 1.2×16 GB/T91-2000 1 39 Friction plate 75.20.105 2
24 Spacer, shaft, linkage 5134241/1.10.036 1 40 Support, hand throttle control SZ804.20.011-2 1
25 Linkage and sleeve unit 5127682/1.10.027 1 41 Rubber sleeve, handle 15.20.110-1 1
26 Grip, adjusting accelerator rod 5117242/1.10.028 1 42 Handle unit, hand throttle SZ804.20.010 1
27 Nut M6-Zn.D GB/T6170-2000 1 43 Cover plate, hand throttle LHSYM-021.01 1
28 Mount, cable, hand throttle 5110214/1.10.054 1 44 Dust boot, accelerator pedal SZ804.20.109 1
29 Bolt M6×25 GB/T5783-2000 1 45 Hand throttle assembly SZ804.20.052 1
30
Load transfer bracket, hand
throttle
Load transfer bracket,
hand throttle
1

31
Cable assembly, hand throttle（Core
wire, stainless steel）
SZ804.20.108A 1

32 Nut M14×1.5-6 GB/T889-86 1
33 Washer, hand throttle control 5133910/1.10.055A 1
34 Bushing, spring, hand throttle control 5133911/1.10.055B 1
35 Spring, lever, hand throttle 5105248/1.10.056 1
36 Pin B5×20 GB/T119-86 1

1
Tension spring, fuel cut-off
cable
1.10.354A/5116803 1

2 Bracket, engine shut-off cable 1.10.359/885147284 1
3 Nut M4 10112/10794011 1
4 Screw M4×16 10312/10444814 1
5
Cable assembly, hand fuel
cut-off(Core wire, stainless steel)
LX954.20.016A 1
6 Hexagon thin nut M12-Zn.D GB/T 6172-2000 1

1 Clutch, 11” SZ904.21.010 1 7 Oil seal 45×85×10 5144379/1.25.030 1
1.1
Driven disc assembly, main
clutch
L-03028-0100-07 1 8 Retainer ring 85 11062176/12246 1
1.2
Driven disc assembly, auxiliary
clutch
L-03028-0836-01 1 9 Bearing retainer 63×84.5×3 SZ804.21.702 1
1.3 Compressing disc, main clutch L-02103-0730-60 1 10 Bearing 6008.2RS GB/T276 1
1.4
Compressing disc, auxiliary
clutch
L-02103-0729-00 1 11 Bolt M8×95-Zn.D GB/T5782-2000 12
1.5
Auxiliary disengaging rod
assembly
L-02615-0050-02 1 12 Washer 8-Zn.D GB/T7244-1987 12
1.6 Main disengaging rod assembly L-02615-0049-01 1 13 Shaft, clutch, PTO 5137585/1.25.351 1
2 Shaft unit, main clutch 5125360/1.25.013A 1
3 Bearing 6209E（209） GB/T276 1
4
Oil seal 25×31×7, shaft, main
clutch
4985295/1.28.174 1

5 Retainer ring 85 11062176/12246 2
6 Retainer ring 45 11069076/12245 2
