Description

D38-000-148+B SHANGHAI DIESEL turbocharger 750223-5006S Bus

1 530-1004054 连杆螺栓 Connecting rod bolt 2
2 530-1004053 连杆盖 Connecting rod cover 1
3 530-1004019 连杆轴瓦 Connecting rod bearing shell 2
4 1530-1004051 连杆体 Connecting rod block 1
5 Q43040 挡圈40 Retainer 40 2
6 430-1004019 活塞销 Piston pin 1
7 E0200-1004202 连杆衬套 Connecting rod bushing 1
8 E2100-1004001A 活塞 Piston 1
9 530-1004016 第一道气环 First gaseous ring 1
10 530-1004017A 第二道气环 Second gaseous ring 1
11 530-1004030 油环总成 Oil ring assembly 1

1 E0200-1005015 曲轴 Crankshaft 1
2 530-1005014 主轴瓦(下) Main bearing shell(low) 4
3 530-1005013 主轴瓦(上) Main bearing shell (upper) 4
4 530-1005012 曲轴止推轴瓦(下) Crankshaft thrust bearing shell(low) 1
5 530-1005011 曲轴止推轴瓦(上) Crankshaft thrust bearing shell(upper) 1
6 Q5511245 键12X45 Key12X45 1
7 GB/T1096-C1232 键C12X32 KeyC12X32 1
8 E2100-1005002 曲轴正时齿轮 Crankshaft timing gear
9 E2000-1005022 机油泵驱动齿轮 Fuel pump drive gear 1
10 530-1005024 垫片 Washer 1
11 YC208-B04370 O形圈2.65X43.7 0-ring 1
12 530-1005017A 皮带轮隔套 Belt pulley spacer sleeve 1
13 E2100-1005140A 减振器组件 Vibration parts 1
14 530-1005018B 曲轴头垫片Ⅰ Crankshaft head washer Ⅰ 1
15 530-1005021B 皮带轮压紧螺栓 Belt tension bolt 1
