Description

A6500-1118100-135 yuchai turbocharger 737923-5011S

HA03301 YN33CR-03.04B 缸盖前盖板和节温器盖合件
Cylinder head front cover and
thermostat cover Assembly.
1

1
X0281002
209
A 280 130 147 水温传感器 Coolant temperature sensor 1

/ / / / / / /
3 GB/T 5782 螺栓 Bolt M8×50 2
4 GB/T 5783 螺栓 Bolt M8×25 2
5 GB 93 垫圈 Sping washer 8 4
6 GB/T 97.1 垫圈 Washer 8 4
7 4100QB-03.04-004 矩形垫圈 Rectangle washer 1
8 4100QBZL-03.04-003 节温器盖 thermostat cover 1
9 GB/T 5783 螺栓 Bolt M8×50 3
10 GB 93 垫圈 Sping washer 8 3
11 GB/T 97.1 垫圈 Washer 8 3
12 HA0658 4102QB-06-017A 小循环胶管 Rubber tube, partial circulatioin 1 用于 YN38CRD
13 ZB J15 001-87 喉箍 Clamp d40 2
14 调温器总成 Coolerstat assy 1
15 4100QBZL-03.04-002 节温器盖垫片 Thermostat cover washer 1
16 YN33CR-03.04-001A 缸盖前盖板 Cylinder head front cover 1
17 HA0332 4100QB-03-010 缸盖前盖板垫片 Washer, cylinder head front cover 1

1 GB/T 5783 螺栓 Bolt M8×40 4
2 GB 93 垫圈 Sping washer 8 4
3 GB/T 97.1 垫圈 Washer 8 4
4 HA0630 4100QB-06-001 锁紧垫片 Lock shim 1
5 HA06054 Z490-28-7 Z490-28-7W Fan assy φ450 1
6 HA06750 4100QB-06-008B-K 风扇垫块 Seat pad, fan 厚 22 1
6 HA06751 4100QBZ-06-008B-D 风扇垫块 Seat pad, fan 厚 40 1
7 HA05431 7PK1279 多楔带 / 7PK1279 1
8 HA06002 YN33CR-06-015A 水泵皮带轮 Water pump belt pulley 1
9 GB/T 6170 螺母 Nut M8 4
10 GB 93 垫圈 Sping washer 8 4
11 GB/T 97.1 垫圈 Washer 8 4
12 GB 898 螺柱 Bolt AM8×45 3
13 GB 898 螺柱 Bolt AM8×70 1
14 HA069L YN33-06.01-G-L 水泵总成 Water pump assy 1
15 HA03137 4100QB-03.04-008-NJ 堵塞 Plug 1
16 HA06730 4100QB-06-018A-EQ 暖水回水螺套 Warm water return sleeve 1
17 HA0640 4100QB-06-011A 水泵垫片 Water pump washer 1
