Description

4110000133 SDLG EXCAVATOR 2270-1025 sprocket

1702P1E828A0 主壳体 HOUSING SHIFT UNIT
Q5210622 圆柱销 PIN
1702P1E729A0 卡位锁块 DETENT LEVER
Q5210820 圆柱销 PIN
1702P1E829A0 上壳体垫片 GASKET
1702P1E815A0 上壳体组件 COVER HOUSING TOP UNIT
Q40108 平垫圈 PLAIN WASHER
Q150B0825 六角头螺栓 HEXAGON SCREW
1702P1E819A0 选档拨头防尘帽 PROTECTION CAP
Q150B0880 六角头螺栓 HEXAGON SCREW
1702P1E816A0 上壳体 COVER HOUSING TOP
1702P1E821A0 油封 SHAFT SEAL
1702P1E822A0 带保持架的冲压外圈滚针轴承 NEEDLE BUSH
1702P1E818A0 选档拨头轴 LEVER LANE SELECTION SHAFT
1702P1E817A0 选档拨头 LEVER LANE SELECTION FINGER
Q43114 轴用弹性挡圈 EXTERNAL CIRCLIP

1702P1E851A0 带保持架的冲压外圈滚针轴承 NEEDLE BUSH
Q5211024 圆柱销 PIN
1702P1E849A0 助力气缸输入拨头 ACTUATION INPUT LEVER
Q5210622 圆柱销 PIN
1702P1E852A0 输入拨块 INPUT FINGER
1702P1E848A0 助力气缸输出拨头 ACTUATION OUTPUT LEVER

1701P1E308A0 调整垫片 ADJUTING WASHER
1701P1E309A0 调整垫片 ADJUTING WASHER
1701P1E311A0 调整垫片 ADJUTING WASHER
1701P1E312A0 调整垫片 ADJUTING WASHER
1701P1E313A0 调整垫片 ADJUTING WASHER
1701P1E284A0 定位环 LOCKED RING
1701P1E277A0 开口环 CLIP RING
1701P1E278A0 开口环 CLIP RING
1701P1E279A0 开口环 CLIP RING
1701P1E281A0 开口环 CLIP RING
1701P1E282A0 开口环 CLIP RING
1701P1E283A0 开口环 CLIP RING
1701P1E286A0 开口环 CLIP RING
1701P1E287A0 开口环 CLIP RING
1701P1E288A0 开口环 CLIP RING
