Description

4100ZL.10.10-1 CHAOYANG turbocharger 751412-5009S

1 291-1306028A 放气管接头 Bleeder pipe joint 1
2 150-1306012 节温器盖 Thermostat cover 1
3 Q150B0828 螺栓M8X28 Bolt M8X28 4
4 Q40308 垫圈8 Washer8 4
5 Q40108 垫圈8 Washer8 4
6 150-1306013A 节温器盖垫片 Thermostat seat cover washer 1
7 Q618B03 螺塞NPT 3/8 Screw plug NPT3/8 2
8 150-1306014A 蜡式节温器 Thermostat 2
9 B30-1306012 节温器垫片 Thermostat washr 1
10 E2000-1306001A 节温器座 Thermostat seat 1
11 Q1841255 螺栓M12X55 Bolt M12X55 3
12 Q/YC198-14 螺塞M14X1.5 Screw plug M14X1.5 1
13 Q/YC147.1-49 环箍49 Hoop 49 2
14 150-1306015 回水胶管 Water return pipe 1
15 Q1841270 螺栓M12X70 Bolt M12X70 3
16 294-1306016B 螺塞 Screw plug 1
17 Q618B06 螺塞NPT 3/4 Screw plug NPT 3/4 1
18  Q/YC149-27 复合式密封垫圈27 Seal ring 27 1

1 1530-1307029 水泵盖板垫片 Water pump cover plate washer 1
2 E2100-1307020C 水泵部件 Water pump parts 1
3 Q150B0860TF2 螺栓M8X60 Bolt M8×60 3
4 G04F1-1307104 水泵附加皮带轮 Water pump accessional pulley 1
5 E2100-1307002 水泵皮带 Water pump belt 1
6 Q1841050TF2 螺栓M10X50 Bolt M10X50 1
7 Q1200860TF2 螺柱M8X60 Bolt M8X60 2
8 Q340B08 螺母M8 Nut M8 2
9 Q40308 垫圈8 Washer8 5
10  Q40108 垫圈8 Washer8 5
