Description

111801044D FAW turbocharger 727528-5009S CA6DE2-24

1 B3221-1009020B 油底壳焊接件 Oil sump weldment 1
2 6105Q-1009030 放油塞总成 Oil drain plug assembly 1
3 Q/YC149-27 复合式密封垫圈 27 Compound seal washer 27 1 易损件 EWP
4 Q/YC1820820 螺栓 M8X20 Bolt M8X20 24
5 Q40308 垫圈 8 Washer 8 35
6 6105Q-3509013 垫圈 Washer 26
7 Q/YC1820816 螺栓 M8X16 Bolt M8X16 6
8 D30-1009102A 垫圈 Washer 4
9 J3200-1009012 油底壳垫片 Oil sump gasket 1 易损件 EWP
10 151-1002082 管夹 Pipe clamp 2
11 Q150B0820 螺栓 M8X20 Bolt M8X20 5
12 Q40108 垫圈 8 Washer 8 5
13 Q340B08 螺母 M8 Nut M8 2
14 B3221-1009044A 支架 Bracket 1
15 B3221-1009041 油标尺软套管 Oil dipstick teleflex 1
16 B3221-1009045A 支架(I) Bracket (I) 1
17 F30SA-1028170 油标尺座组件 Oil dipstick seat parts 1
18 B3221-1009050 油标尺焊接件 Oil dipstick weldment 1
19 Q67616 环箍 Loop hoop 2

1 Q/YC1820820TF2 螺栓 M8X20 Bolt M8X20 2
2 6105QA-1010150B 油管支架焊接件 Oil pipe bracket welded part 1
3 430-1010001A 垫片结合件 Gasket union part 1
4 Q150B0816TF2 螺栓 M8X16 Bolt M8X16 1
5 430D-1010030 吸油管焊接件 Oil suction pipe weldment 1
6 6105QA-1010130B 滤网总成 Filter screen assembly 1
7 Q150B0860TF2 螺栓 M8X60 Bolt M8X60 1
8 Q40308 垫圈 8 Washer 8 4
9 Q40008 垫圈 8 Washer 8 1
10 430-1010002 管夹 Pipe clamp 1
已随吸油管焊接件带来 With
oil suction pipe weldment
