Description
0750112141 prof seal ring 4110000076352 4110000076099
1 150105-00582 TURBOCHARGER ASS’Y 1 1 1 1
2 150105-00583 TURBOCHARGER ASS’Y 1 1 1 1
3 65.09901-0033 GASKET ; TURBOCHARGER 2 2 2 2
4 65.90201-0076 BOLT ; STUD 8 8 8 8
5 65.90535-0001 NUT 8 8 8 8
6 65.08901-0063 GASKET ; EXHAUST ELBOW 2 2 2 2
7 06.06226-0808 BOLT ; STUD M10x30 12 12 12 12
8 420214-00249 PIPE ; OIL DELIVERY 1 1 1 1
9 65.97401-0110A CLIP ; PIPE 1 1 1 1
10 420214-00374 PIPE ; OIL DELIVERY 1 1 1 1
11 65.96601-0046B GASKET ; OIL PIPE ADAPTER 2 2 2 2
12 06.01913-3114 BOLT ASS’Y M8x22 4 4 4 4
13 65.91701-0086 SPACER 1 1 1 1
14 06.01913-3124 BOLT ASS’Y M8x65 1 1 1 1
15 110928-00360 HOLDER 1 1 1 1
16 65.97401-0110A CLIP ; PIPE 1 1 1 1
17 06.01923-3112 BOLT ASS’Y M8x18 1 1 1 1
18 06.56190-0706 RING ; SEAL A14x20 3 3 3 3
19 65.98150-0071 SCREW ; HOLLOW 1 1 1 1
20 65.96601-0067 GASKET ; OIL RETURN 2 2 2 2
21 420217-00227 PIPE ; OIL RETURN 2 2 2 2
22 06.01913-3114 BOLT ASS’Y M8x22 4 4 4 4
23 420107-00301 HOSE ; OIL 2 2 2 2
24 65.97440-0103 CLAMP ; HOSE 4 4 4 4
25 65.98131-0071 SCREW ; CONNECTION 2 2 2 2
26 06.56190-0728 RING ; SEAL 2 2 2 2
27 06.01913-3217 BOLT M10x30 1 1 1 1
1 240401-00140 STAKE ; INTAKE 2 2 2 2
2 65.96501-0075 O-RING 2 2 2 2
3 65.08212-0002 INSERT 2 2 2 2
4 65.97450-5006 V-CLAMP 2 2 2 2
5 420209-00196 PIPE ; INLET 2 2 2 2
6 65.96501-0420 O-RING 2 2 2 2
7 65.97450-5001A CLAMP 2 2 2 2
8 420209-00276 PIPE ; INLET 2 2 2 2
9 420108-00152 HOSE ; RUBBER 4 4 4 4
10 65.97440-5005 CLAMP ; HOSE 8 8 8 8
11 65.97401-0397 CLIP ; PIPE 2 2 2 2
12 110928-00480 HOLDER 2 2 2 2
13 65.90535-0003 NUT 4 4 4 4
14 06.01923-3117 BOLT ASS’Y M8x30 2 2 2 2
15 420209-00197 PIPE ; INLET 2 2 2 2
16 65.09905-0004 GASKET ; AIR PIPE 2 2 2 2
17 06.01953-3320 BOLT ASS’Y 8 8 8 8
18 420108-00111 HOSE ; RUBBER 2 2 2 2
19 420108-01165 HOSE ; RUBBER 2 2 2 2
1 65.10101-7051 NOZZLE HOLDER ASS’Y 10 10 10 10
1-1 65.10102-6047 NOZZLE ; INJECTION 1 1 1 1
2 65.10108-0006 PRESSURE SCREW KIT 10 10 10 10
3 65.98701-0065 SEALRING 10 10 10 10
4 65.98701-0006 SEAL ; NOZZLE HOLDER HOLE 10 10 10 10
1 420208-00399 INJECTION PIPE ASS’Y 1 1 1 1
2 420208-00400 INJECTION PIPE ASS’Y 1 1 1 1
3 65.90535-0003 NUT 3 3 3 3
